Viking K4225 Cast Iron Rotary Gear Pump 2″– 60 GPM, Heavy-Duty Industrial Pump

HAS A 1-1/8” DIAMETER SHAFT / 3” ID X 7.5” OD PORTS / 400PSIG STATIC / 450F MAX TEMP.

The Viking K4225 is a positive displacement internal gear pump designed for heavy-duty applications. It features a robust steel shaft and a hard steel idler pin, ensuring durability. The pump’s components include a cast iron rotor and idler, along with carbon graphite bushings for the idler and bracket, which contribute to its long-lasting performance under varying conditions.

Product Specifications:

• Brand: Viking
• Model: K4225
• Pump Type: Rotary Gear Pump
• Material: Cast Iron
• Flow Rate: 60 GPM (Gallons Per Minute)
• Port Size: 2″ NPT (Inlet & Outlet)
• Max Pressure: Varies based on application (Consult Viking specifications)
• Viscosity Range: Suitable for low to high-viscosity fluids
• Rotation: Clockwise (Reversible with proper configuration)
• Mounting: Horizontal
• Seal Type: Mechanical Seal / Packed (Varies by configuration)
• Applications: Lubricants, fuels, oils, resins, chemicals, and other industrial liquids
• Construction Features:
  • Heavy-duty cast iron housing for durability
  • Precision-machined internal gears for efficient performance
  • Designed for continuous-duty industrial use
  • Compatible with various drive options (motor, belt, direct drive)

This Viking K4225 rotary gear pump is ideal for industries requiring a robust and efficient fluid transfer solution, including chemical processing, manufacturing, and petroleum applications.
