Petersen Pipe Plug Multi-Flex Inflatable Plug 124-030-H 30”, Heavy Duty

The Petersen Pipe Plug Multi-Flex Inflatable Plug 124-030-H 30″ is a heavy-duty inflatable pipe plug designed for high-expansion and lower-pressure gas applications. Here are some key specifications:

• Deflated Diameter: 12 inches (305 mm)

• Maximum Diameter: 30 inches (762 mm)

• Material: Outer ply made of ballistic nylon reinforced with nitrile

• Inflation Port: 2″ MNPT to 1/2″ QD plug

• Pressure Monitoring Port: 1/4″ QD Cplg

• Pipeline Pressure Max Head: 12.5 psi (0.86 bar)/28.8′ (8.79 m)

• Inflation Max Pressure: 25 psi (1.72 bar)

• Maximum Service Temperature: 200°F (93.33°C)

• Shipping Weight: 69 lbs (31.3 kg)
