Square D FAL32040 40A 3 Pole Molded Case Circuit Breaker 240V

$100.00

1 in stock

Category: Tag:

The Square D FAL32040 is a circuit breaker from the Square D FAL Series, manufactured by Schneider Electric. This model is widely used in industrial and commercial electrical systems for overcurrent protection.

Key Specifications of the FAL32040

  1. Type:
    • Molded Case Circuit Breaker (MCCB) from the FA Frame Series.
  2. Amperage Rating:
    • 40 Amps.
  3. Voltage Rating:
    • Suitable for systems up to 240 Volts AC.
  4. Poles:
    • 3-pole configuration, providing overcurrent protection for three-phase systems.
  5. Interrupting Capacity:
    • 25 kAIC (kiloampere interrupting capacity) at 240V AC, meaning it can safely interrupt fault currents up to 25,000 amperes.
  6. Frame Size:
    • FAL (FA Frame), designed for mid-range current protection.
  7. Mounting:
    • Bolt-on style for secure installation in compatible panelboards or switchboards.
  8. Trip Unit:
    • Thermal-Magnetic trip mechanism:
      • Thermal Trip: Protects against overload conditions.
      • Magnetic Trip: Responds instantly to short-circuit conditions.
