Festo MS6-SV-1/2-E-10V24-SO-AG Quick Exhaust Valve 548717 50-145psi -NIB

The Festo MS6-SV-1/2-E-10V24-SO-AG is a soft start/quick exhaust valve designed for compressed air systems. It features:

• Operating pressure: 3.5 to 10 bar
• Flow rate: 4,300 l/min (standard nominal), 9,000 l/min (exhaust)
• Voltage: 24V DC with ±10% fluctuation
• Valve function: 3/2 closed, monostable
• Switching times: 130 ms (on), 40 ms (off)
• Protection class: IP65
• Mounting: Any position, line installation possible
• Materials: Die-cast aluminum housing, NBR seals, high-alloy stainless steel piston rod

This valve complies with DIN EN ISO 13849-1 safety standards, has SIL 3 and PL e certifications, and features an LED status display. It is suitable for oil-lubricated or non-lubricated operation and is resistant to moderate corrosion (CRC 2).
